Labtronixed Inc is Manufacturer of Auto Flipping Tape Edge Machine, CTEC Looper Tape Edge Machine, Mattress Automatic Tape Edge Machine, Semi-Automatic Tape Edge Machine And Typical 300u Tape Edge Machine in Faridabad India.
Labtronixed Inc is manufacturer of Auto flipping tape edge machine for heavy mattresses. For the sewing head lift and pitch part of the re-optimized design, so that more easily lift, a big lift range, the needle in the horizontal direction of the amount of change is smaller, can easily qualified 3 to 40 cm mattress sewing. This model is the first choice for the production of high-grade heavy-duty mattresses in Faridabad India.
Features
- By using the structure of moving mattress and fixing sewing head,
- Model LTI-AFTEM-01 tape edge closing machine is ideal mate equipment for automatic product line of mattress production.
- It could make the mattress move in or move out
- Corner slow down and flip automatically
- Its unique abilities such as sewing head auto raising or lowering at the corner,
- Speed auto slowdown at corner
- Using the advanced chain stitch machine head
- Sewing speed auto recovery after passing corner
- Adjustable sewing head tilting angle
- Adjustable sewing head lift, Adjustable sewing speed, Adjustable conveyer speed, Greatly increases the sewing quality
Technical Specification
|
Model No:- |
LTI-AFTEM-01 |
|
Machine Type |
Automatic |
|
Capacity |
16-20pcs./hour |
|
Sewing Head Type |
chain stitch |
|
Sewing Head Lifting Range |
0 - 340 mm |
|
Tilting Angle of Sewing Head |
25 - 65 mm |
|
Table Convener Belt Speed |
10 - 14m/min |
|
Mattress Thickness |
30 - 400 mm |
|
Sewing Head Speed |
1642-2740 r/min |
|
Motor Power |
3.6 KW |
|
Air Pressure |
0.6 - 0.8 Mpa |
|
Work Table Size |
4020x2020 mm |
