Application & Features:
Suitable for making PU-Foam Mattress, Rebounded Foam Mattress, Coir Mattress, Spring Mattress Etc. rather than moving around with fix head. Head can adjust up and down according to the mattress height by manual lever. Labtronixed Inc is Manufacturer of CTEC Looper Tape Edge Machine has control AC Drive in our tape edge machine. you can set according to you rpm and auto slow down to the mattress corner.
Technical Specification
|
Capacity |
10-15unit/hour |
|
Machine Type |
Automatic |
|
Brand |
LABTRO |
|
Frequency |
50Hz |
|
Material |
Standard |
|
Phase |
Single Phase |
|
Power Consumption |
1.75kw |
|
Voltage |
220AVC |
|
Country of Origin |
Made in India |
|
Corner Speed Auto Slow Down |
Yes (Control by AC Drive) |
|
Chain Stitch Head (Looper) |
CTEC (Taiwan) |
|
Working Angle of Swing Head |
35-55 degree (Manual) |
|
Mattress Thickness Range |
50-400mm |
|
Lift of Working Table |
Automatic (By Push Button) |
|
Size of Working Table |
54" x 75" |
|
Carriage Speed |
1100~4000rpm/min (High Speed) |
|
Motor Type |
AC Induction Motor (Siemens/Crompton) |
|
Rated Power |
220VAC/Single Phase/50-60Hz |
